Wireless mono audio transmission system, 823-832 MHz

• Wireless audio transmission system with UHF PLL technology
• For wireless transmission of audio line and microphone signals (mono) with one transmitter and one or more receivers
• Duplex gap 823-832 MHz
• Parallel use of up to 4 transmitters possible
• Operating range up to 50 m
• Audio line output and earphone connection via 3.5 mm mono jack
• 16 channels selectable
• Volume level control
• RF reception indicator
• LED battery indicator
• Robust metal fixing clip
• Power supply via 2 x 1.2 V NiMH rech. battery AA size (not included)
• Micro USB charging port
• License-free in large parts of the EU
• Mute function: On/off/mute switch
• Power supply: Battery/battery pack

Type:
16-channel PLL audio receiver
Frequency range:
823-832 MHz
Range:
min. 50 m
Modulation:
FM
Frequency stability:
10 ppm
Pilot frequency:
32,768 kHz
S/N ratio:
>80 dB
Line/earphone input:
3.5 mm mono jack
Max. output voltage:
500 mV
Power supply:
2 x 1.2 V rechargeable NiMH battery or 2 x 1.5-V battery (type AA)
Battery operation:
approx. 6 hours
Charging time:
approx. 3 hours
Dimensions:
110 x 65 x 27 mm (w/o antenna)
Frequency band:
UHF 823 - 832 MHz
Weight:
0,093 kg
Height:
11 cm
Depth:
2,7 cm
Width:
6,5 cm
Material:
Plastic
