EUROLITE MD-1515 Safety Rotary Motor

Eurolite MD-1515 Säkerhetsrotationsmotor

Art nr:50301300
381 kr

I lager / Leveranstid ca. 4-8 vardagar

  • ✓ Trygga betalsätt
  • ✓ 30 dagar ångerrätt

Produktbeskrivning

Mirror ball motor for mirror balls up to 40 cm diameter

  • The maximum load always means the mirror ball weight including chains and the fixation material
  • 2 chains and 4 quick links must be ordered separately
  • 1,5 rotations per minute
  • The motor always has to be installed with a secondary safety attachment
  • Before taking into operation for the first time, the installation has to be approved by an expert
  • Control via plug and play
  • Suitable for a mirror ball with a diameter of up to 40 cm
  • For application areas such as: Clubs/dancing school

Package contents

  • 1 x motor, 1 x chain link, 3 x mounting material, 3 x screw, 1 x user manual


Power supply:
230 V AC, 50 Hz
Power consumption:
4 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Fixed power supply cord with safety plug
Cable construction:
3 x 0,75 mm² H05VV-F
Cable length:
Approx. 0,9 m
Rotation:
1,5 RPM - 1,8 RPM , 360 ° forward/backward
Control:
Plug and play
Maximum load:
4 kg
Max. mirror ball diameter:
40 cm (EUROLITE)
Housing color:
Black
Diameter mounting holes:
3 x Ø5mm
Material:
Metal
Dimensions:
Height: 9 cm
Diameter: Ø 10,8 cm
Weight:
410 g
Chain link
Material:
Steel
Color:
Silver
Dimensions:
Diameter: Ø 2,5 mm
