Fresnel spotlight, dim to warm, 170 W warm white/amber LED, CRI >90, quiet, DMX

• New LED technology that simulates the color temperature curve of a halogen lamp when dimming
• Rugged metal housing
• 1 powerful LED 170 W COB (chip-on-board) Dim to warm (homogenous color mix)
• Zoom motor-driven
• The device is cooled by temperature-controlled fan
• Control via RDM; DMX
• Flicker-free
• With a beam angle of 8° - 55°
• Very high color rendering index (CRI)
• With Mounting bracket
• LCD display
• Exact 16 bit resolution at Dimmer
• Color blend stepless; Dimmer electronic; Dimmer speed (step response) adjustable; dimmer curves adjustable
• Strobe effect
• Preprogrammed in Light´J; Light Captain
• Rubber feet
• Mains input and output for power linking up to 8 units

Package contents

• 1 x spotlight, 1 x user manual, 1 x power cord, 1 x barndoor, 1 x filter frame

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
150 W
IP classification:
IP20
Power connection:
Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output:
P-Con (gray), mounting version
LED:
1 x 170 W COB (chip-on-board) Dim to warm (homogenous color mix)
Equipment:
Zoom motor-driven
DMX channels:
2; 6; 7
DMX input:
1 x 3-pin XLR (M) mounting version
1 x 5-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version
1 x 5-pin XLR (F) mounting version
Cooling:
Temperature-controlled fan
Control:
RDM; DMX
Preprogrammed in:
Light´J; Light Captain
Beam angle:
8° - 55°
Beam angle (1/2 peak):
8 - 39°
Beam angle (1/10 peak):
12 - 55°
Color rendering index (CRI):
96 Ra
Luminous flux:
5093 lm
Housing color:
Black
Attachment system:
Mounting bracket
Display type:
LCD display
Transport aid:
Rubber feet
Dimensions:
Length: 45,7 cm
Width: 33,6 cm
Height: 39,8 cm
Weight:
9,40 kg
Noise classification:
Class 2 (slight noise)
Energy efficiency class (A - G):
G
