Splitter with 6 galvanically isolated outputs, 3-pin & 5-pin XLR sockets

• DMX splitter for splitting one DMX input signal to 6 DMX outputs
• Input and outputs galvanically isolated
• Input and outputs with a set of respective power supply and internal fuse
• Each DMX output with independent driver and status indicator
• (19") 48.3 cm rack installation 1 U

Package contents

• 1 x device, 1 x user manual

Power supply:
230 V AC, 50 Hz
Power consumption:
35 W
Power connection:
Fixed power supply cord with safety plug
DMX input:
1 x 3-pin XLR (M) mounting version
1 x 5-pin XLR (M) mounting version
DMX output:
6 x 3-pin XLR (F) mounting version Separate (galvanic) with independent driver and status indicator
6 x 5-pin XLR (F) mounting version Separate (galvanic) with independent driver and status indicator
1 x 5-pin XLR (F) mounting version Bypass
1 x 3-pin XLR (F) mounting version Bypass
Control elements:
Bypass/terminating resistor switch, power switch
Housing design:
(19") 48.3 cm rack installation 1 U
Dimensions:
Width: 48,3 cm
Depth: 20 cm
Height: 4,45 cm
Weight:
3,31 kg
