2-fold power and DMX splitter for truss mounting

• Reliable power and DMX distributor
• 1 P-Con input to 2 outputs, max. 10 A
• 1 DMX input to 2 outputs
• Input and outputs galvanically isolated
• Rugged metal housing
• Each DMX output with independent driver and status indicator

Package contents

• 1 x device, 1 x power cord, 1 x user manual

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
2 W
Output current:
Max. 2 x 5 A per channal
Power connection:
Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output:
2 x P-Con (gray), mounting version
DMX input:
3-pin XLR (M)
DMX output:
2 x 3-pin XLR (F) Separate (galvanic) with independent driver and status indicator
Status LED:
Power, DMX
Dimensions:
Width: 9 cm
Depth: 10 cm
Height: 13,6 cm
Weight:
1,00 kg
