Compact strobe with 98 SMD LEDs & DMX, each ring individually controlable

• Flat version requires minimal space when mounting
• 98 powerful LEDs SMD 5730 cold white (CW) (homogenous color mix)
  5 segments separate controlling
• Strobe effect; Blinder effect
• Integrated show programs
• The device is cooled by cooling fan
• Control via stand-alone; DMX; Sound to light via Microphone; IR remote control
• Flicker-free
• With double bracket
• Dimmer electronic
• Preprogrammed in LED PC-Control 512; Light Captain
• Mains input and output for power linking up to 8 units

Package contents

• 1 x light effect, 1 x user manual, 1 x power cord, 1 x remote control, 1 x battery

Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
24 W
Protection class:
Protection class II
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power output:
1 x IEC connector (F) mounting version
Lamp type:
LED lamp
LED:
98 x SMD 5730 cold white (CW) (homogenous color mix)
Flash rate:
0 - 20 Hz
DMX channels:
4; 9
DMX input:
1 x 3-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version
Cooling:
Cooling fan
Control:
Stand-alone; DMX; Sound to light via Microphone; IR remote control
Preprogrammed in:
LED PC-Control 512; Light Captain
Attachment system:
Double bracket
Dimensions:
Width: 21,5 cm
Depth: 12 cm
Height: 24,5 cm
Weight:
1,20 kg
Remote control
Battery:
1 x Button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
